Sheet Metal Housing Cover

Sheet metal CPU enclosure designed for real-world fabrication and precise fitment.

This project involves the design and detailing of a sheet metal housing cover for a computer CPU enclosure using SolidWorks sheet metal tools. The model incorporates proper bend parameters, thickness control, and manufacturing constraints to ensure real-world feasibility.

CPU enclosure coverBend-controlled designFabrication-ready documentation

Structural strength and precise fitment

Laser-cut and bend-ready output

Flat-pattern fabrication workflow

Project Scope

The housing cover was developed as a production-conscious sheet metal part for a CPU enclosure. The design balances enclosure protection, bend feasibility, thickness control, and manufacturing constraints so the model can move cleanly into fabrication.

Built using SolidWorks sheet metal tools for controlled bends and profile accuracy.
Designed with thickness control, bend parameters, and manufacturing feasibility in mind.
Ensures structural strength and precise fitment for the CPU enclosure assembly.

Manufacturing Output

The final output is organized for direct use in fabrication, with the required drawing information and flat-pattern references needed for production planning and shop-floor execution.

Manufacturing drawing includes dimensions, bend details, and hole references.
Flat pattern and cut-list information support material planning and quantity control.
Ready for laser cutting, bending, and full fabrication workflow.

Project Visuals

Supporting images for this project

Sheet metal housing cover render — Primary SolidWorks model showing formed geometry and perforated center section.

Sheet metal housing cover drawing — Detailed manufacturing sheet with dimensions, feature callouts, and sectional details.
